1m (3.28ft) Generic SFP-25G-AOC-1M Compatible SFP28 to SFP28 AOC 25GBASE-CR 25Gbps Multi Mode Fiber Active Optical Cable
Dawnray’s SFP-25G-AOC-1M AOC is a 25Gbps SFP28 to SFP28 active optical cable for use in 25GBASE Ethernet network. SFP28 AOC provides 25.78Gb/s throughput for 1m interconnection with laser-optimized multi-mode fiber optical cable. This AOC is fully compliant with SFP28 Multi-Source Agreement (MSA), IEEE 802.3by 25GBASE-CR and 25GAUI standard. Its optical fiber cable is pre-terminated with MSA compliant 20-pin edge type connectors. Standard length options cover from 1 meter to 30 meters. Built-in Digital Diagnostic Monitoring/Digital Optical Monitoring (DDM/DOM) support is present for real-time performance monitoring via 2-wire (TWI/I2C) interface. Our AOCs are factory pre-programmed for compatibility, perform alternatively to generic/MSA active optical cables.
Feature
- Hot pluggable SFP28 to SFP28 AOC active optical cable
- Data rate up to 25.78125Gbps
- Pre-terminated multi-mode fiber cable
- 25.78125Gbps NRZ retimed 25GAUI electrical interface
- Minimum bending radius 7.5mm
- Built-in digital diagnostic via 2-wire interface
- Single 3.3V power supply voltage
- Power consumption < 1W
- Ambient temperature range 0 to 70°C for commercial application
- Compliant with SFF-8402, SFF-8432, SFF-8419, SFF-8472
- Compliant with IEEE 802.3by 25GBASE-CR
- Compliant with RoHS, REACH, CE, FCC standards
Application
- 25G Ethernet
- Data Center
Specification
Part Number | SFP-25G-AOC-1M | Topology | SFP28 to SFP28 |
Max Data Rate | 25.78125Gbps | Cable Length | 1m (3.28ft) |
Cable Type | OM3 Multi Mode Fiber | Jacket Meterial | OFNP |
Minimum Bend Radius | 7.5mm | Signal Conditioner | Retimer for TX and RX |
Modulation Format | NRZ | Host FEC | Support |
Power Consumption | 1W | Commercial Temperature Range | 0 to 70°C (32 to 158°F) |
