10m (32.81ft) Generic QSFP-56G-AOC-10M Compatible QSFP14 to QSFP14 AOC 4X FDR 56Gbps Multi Mode Fiber Active Optical Cable

10m (32.81ft) Generic QSFP-56G-AOC-10M Compatible QSFP14 to QSFP14 AOC 4X FDR 56Gbps Multi Mode Fiber Active Optical Cable

Dawnray’s QSFP-56G-AOC-10M AOC is a 56Gbps QSFP14 to QSFP14 active optical cable for use in 56G InfiniBand network. QSFP14 AOC provides 56.25Gb/s throughput for 10m interconnection with laser-optimized multi-mode fiber optical cable. This AOC is fully compliant with QSFP14 Multi-Source Agreement (MSA), InfiniBand 4X FDR and XLPPI standard. Its optical fiber cable is pre-terminated with MSA compliant 38-pin edge type connectors. The AOC cable implements 4 independent 14.0625Gbps NRZ transmit and receive signal channels in each fiber for an aggregate 56.25Gbps data rate. Standard length options cover from 1 meter to 30 meters. Built-in Digital Diagnostic Monitoring/Digital Optical Monitoring (DDM/DOM) support is present for real-time performance monitoring via 2-wire (TWI/I2C) interface. Our AOCs are factory pre-programmed for compatibility, perform alternatively to generic/MSA active optical cables.

Feature

• Hot pluggable QSFP14 to QSFP14 AOC active optical cable
• Aggregate data rate up to 56.25Gbps
• Pre-terminated multi-mode fiber cable
• 4x 14.0625Gbps NRZ XLPPI electrical interface
• Minimum bending radius 7.5mm
• Built-in digital diagnostic via 2-wire interface
• Single 3.3V power supply voltage
• Power consumption < 1W
• Ambient temperature range 0 to 70°C for commercial application
• Compliant with SFF-8685, SFF-8661, SFF-8679, SFF-8636
• Compliant with InfiniBand 4X FDR
• Compliant with RoHS, REACH, CE, FCC standards

Application

• 56G 4X FDR InfiniBand
• Data Center
